CNC Abrasive Wire Cut Machine FQT Series

845000.0 INR/Unit

Get a Price/Quote

Product Details:

Product Type Cutting Machine
Technology CNC
Power Source Electricity
Operating Type Automatic
Surface Treatment Coated
Color Black & Red
Warranty 1 Year
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

CNC Abrasive Wire Cut Machine FQT Series Price And Quantity

Minimum Order Quantity 1 Unit
Price 845000.0 INR/Unit

CNC Abrasive Wire Cut Machine FQT Series Product Specifications

Surface Treatment Coated
Operating Type Automatic
Technology CNC
Warranty 1 Year
Color Black & Red
Usage & Applications Industrial
Product Type Cutting Machine
Power Source Electricity

CNC Abrasive Wire Cut Machine FQT Series Trade Information

Supply Ability 10 Unit Per Month
Delivery Time 15-20 Days

Product Description

It is Widely used for cutting graphite electrodes, epoxy plate, hard alloy, marble, jade, optical glass, ceramics, ferrite, semiconductor materials, carbonized silicon and other non conductive material.

Features:

Integrated programming and control software
Graphic tracking
Arbitrary angle rotation
Symmetric machining
Wire broken protection
Power failure protection
Automatic power off after finishing job.
USB port for inputting dxf drawing.
Forward and reverse processing
Analog Processing

Standard Accessories:

PC with Windows 7 / XP
Abrasive Wire
Pneumatic Wire Tighten Device
Ball Screw in X, Y Axis
Tool Box

Specifications:

Model	Unit	FQT-2532	FQT-3240
X Travel	mm	250	320
Y Travel	mm	320	400
Working Table	mm	580x400	710x470
Max. Load on Table	kg	250	300
Max. Cutting Thickness	mm	250	400
Abrasive Wire Dia	mm	0.18-0.35
Movement for hand wheel per cycle	mm	1	1
Pluse Equivalency	mm	0.001	0.001
Roughness	Ra	Ra 0.8-2.0	Ra 0.8-2.0
XY Motor	-	Stepper motor	Stepper motor
Max Cutting Speed	mm/m/in	100	100
Power	KVA	2.0 AC 415V/50 Hz, 3 Phase
Weight	Kg	1000	1000
Machine Dimension	mm	1450x1000x1600	1600x1250x1750
Control Cabinet Dimension	mm	750x680x1650
Software		HL/HH/Autocut Software
Control Cabinet		Vertical
