CNC Wirecut Machine FZT Series

CNC Wirecut Machine FZT Series

Product Details:

X

Product Description

FEATURES
  • Robust frame with C mast.
  • Long travel rail installed in the bottom, which improves the stability for heavy job piece.
  • With height adjustable diamond guider.
  • Four axes independent (X/Y/U/V) work, with Taiwan linear and ball screw. Special Tensioning mechanism for molybdenum wire, keep stable cutting. Stepper motor is standard / Servo motor is optional.
  • Tolerance can be mentioned in +/-0.006 mm, Roughness Ra 0.8
  • Full enclosed cover, Similar to European machine.
  • New generation control cabinet, high efcient.

Specifications:

Model

FZT-320BJ/SF

FZT-400BJ/SF

FZT-500BJ/SF

FZT-630BJ/SF

Table Size mm

700x500

820x600

1000x700

1200x800

Table Travel X/Y mm

400x320

500x400

630x500

800x630

Max Cut Thickness mm

300

300

400

400

Travel Size U/V mm

Normal: 24x24 Large taper: D-60x60 E-130x130 T-240x240

Molybdenum Wire Dia mm

Molybdenum wire 0.10-0.22

Wire Speed m/sec

12,9,7,5,2

Max Cutting Angle

+-3deg/80 mm

Process accuracy (mm)

(Multi-cut): 10x10x30(Square)<=0.006; (one time out)<=0.012 (Multi-cut): (Octagon)<=0.009; (Straightness)<=0.006/50mm

Process roughness(Ra.um)

(Multi-cut): Ra<=0.9 (Micro-pulsepower Ra<=0.8) (Singe-cut): Ra<=1.9

Driving motor

Stepper motor /AC servo motor*(Optional)

Guide screw and track

Precision ball screw/Linear guide way

Tension System

three stage (0/1/2) tension adjustable

Power supply

415V/50Hz, 2.5 Kw

Max. workpiece weight (kg)

450

600

1000

1200

Weight (kg)

1500

1700

2600

3200

Dimension (mm)

1750x1300x2000

1900x1450x2000

2050x1850x2100

2250x2050x2100
