SF300 SF Series EDM Wire Cut

Name: SF300 SF Series EDM Wire Cut
Brand: BERLIN MACHINERIES PRIVATE LIMITED
Price: 2146750 INR
Availability: InStock

Price 2146750 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

SF300 SF Series EDM Wire Cut Specification

Cooling System
Integrated cooling system

Model No
SF Series

Operating Temperature
5C - 40C

Connectivity Options
USB, LAN

Production Capacity
Model-dependent, precision repetitive cycles

Machine Type
High-precision wire cutting EDM

Features
Low wire consumption, high precision, smooth finish, advanced digital controller

Motor Power
0.75 - 1.5 kW

Power Rating
3 kVA (varies by model)

Frame Type
Heavy-duty rigid frame

Voltage
220-415 V (3 Phase)

Drive
Servo Motor Driven

Noise Level
74 dB

Frequency
50/60 Hz

Lubricating System
Automatic lubrication

Accuracy
2 m

Product Type
EDM Wire Cut Machine

Technology
Electrical Discharge Machining (EDM)

Power Source
Electric

Operating Type
Automatic

Power
Approx. 2.5 kW

Surface Treatment
Powder Coated

Dimension (L*W*H)
1150 x 900 x 1750 mm (Typical, model dependent)

Weight (kg)
Approx. 1200 kg

Color
White with red/black accents

Usage & Applications
Precision cutting of complex contours, mold and die making, metal part manufacturing

Cutting Fluid
Deionized water

Software Compatibility
Standard G code, DXF imports

Display
Touchscreen with graphical interface

Max Workpiece Height
220 mm

Max Cut Taper
3 (80 mm thick)

Table Size
400 x 600 mm (or model specific)

Memory Capacity
Up to 500GB (System dependent)

Wire Diameter
0.18 - 0.25 mm usable

Supported Materials
Hardened steel, carbide, graphite, copper, tungsten

Program Storage
User-programmable memory

SF300 SF Series EDM Wire Cut Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
1 Piece Per Month

Delivery Time
2-3 Week

SF300 SF Series EDM Wire Cut About

Experience unbeatable precision with the SF Series EDM Wire Cut, designed for a limited time at an affordable price. In demand for its prime technological advancements, this valiant machine delivers high-precision wire cutting with a table size of 400 x 600 mm and max workpiece height of 220 mm. Compatible with hardened steel, carbide, graphite, copper, and tungsten, it supports advanced programming and DXF imports, powered by an electric servo motor. Enjoy a user-friendly touchscreen, automatic operations, low wire consumption, and smooth finishes-an unparalleled solution for mold-making and complex metal manufacturing.

Applications & Versatility of SF Series EDM Wire Cut

Ideally suited for mold and die making, the SF Series EDM Wire Cut excels in cutting intricate contours and delivering precision in metal parts manufacturing. This machine is widely used at industrial fabrication sites and tool rooms requiring advanced automation. Its ability to handle a variety of hard materials ensures versatility for other applications such as producing durable components for electronics, aerospace, and the medical industry. With its high capacity and accuracy, it is a trusted choice for demanding manufacturing tasks.

Export Market & Streamlined Order Fulfillment

The SF Series EDM Wire Cut is supplied throughout India and boasts a growing export market across various global regions. Our supply ability is robust, supported by efficient transport services and secure shipping practices. Order processing is prompt, ensuring swift turnaround from order placement to delivery. Accepted payment terms are flexible, tailored to support industry needs and foster strong international business relationships. Trust us for reliable logistics, timely deliveries, and comprehensive after-sales support.

FAQ's of SF Series EDM Wire Cut:

Q: How does the SF Series EDM Wire Cut enhance precision in complex metal cutting tasks?

A: The SF Series EDM Wire Cut utilizes advanced CNC programmable control and a robust servo motor drive to deliver exceptionally precise and consistent cuts, allowing for intricate contouring and exact detail essential for mold and die making.

Q: What materials can be processed with this EDM wire cut machine?

A: The SF Series is designed to handle hardened steel, carbide, graphite, copper, and tungsten, making it highly suitable for a wide range of industrial applications requiring durability and versatility.

Q: When is it beneficial to use EDM Wire Cut technology over traditional cutting methods?

A: EDM Wire Cut technology is especially beneficial when working with complex shapes, hardened materials, or when high-precision, smooth finishes are required that traditional cutting tools may struggle to achieve.

Q: Where is the main site of application for this machine?

A: Mainly used in industrial fabrication facilities, mold and die manufacturing units, and precision engineering workshops, the SF Series EDM Wire Cut is ideal for environments demanding high-performance and repeatable results.

Q: What is the process for ordering and receiving the SF Series EDM Wire Cut?

A: The process involves placing an inquiry, confirming technical specifications, securing payment through trusted channels, followed by efficient order processing, secure shipping, and comprehensive installation and support services upon delivery.

Q: How does the machine ensure user convenience and productivity?

A: It features a touchscreen graphical interface, automatic lubrication, user-programmable memory, and advanced connectivity options like USB and LAN, all aimed at streamlined operation and increased operator productivity.
