FZT-400 FZT Series EDM Wire Cut

Name: FZT-400 FZT Series EDM Wire Cut
Brand: BERLIN MACHINERIES PRIVATE LIMITED
Price: 1910299 INR
Availability: InStock

Price 1910299 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

FZT-400 FZT Series EDM Wire Cut Specification

Machine Type
CNC EDM Wire Cut

Frame Type
Rigid Structure

Frequency
50/60 Hz

Voltage
220 V / 380 V

Connectivity Options
USB, RS232

Accuracy
0.015 mm

Model No
FZT-400

Lubricating System
Automatic Lubrication

Cooling System
Water Cooled

Noise Level
Low

Production Capacity
24/7 Operation

Power Rating
3.5 kW

Control System
CNC Controller with Display

Drive
Servo Motor Drive

Motor Power
1.5 kW

Operating Temperature
5C - 40C

Features
High Precision, Stable Performance, Simple Operation

Product Type
EDM Wire Cut Machine

Technology
Electro Discharge Machining (EDM)

Power Source
Electric

Operating Type
CNC

Power
3.5 kW

Surface Treatment
Powder Coated

Dimension (L*W*H)
Approx. 1300 x 1100 x 1800 mm

Weight (kg)
1300 kg

Color
White and Orange

Usage & Applications
Precision cutting of hard materials, Mold manufacturing, Tool parts machining

Display Type
17-inch LCD Touch Screen

Working Speed
100 mm2/min (Maximum)

Wire Threading System
Automatic

Wire Conveyance Speed
Variable, Up to 500 mm/min

Input Voltage
220V 10%

Min Cutting Radius
0.2 mm

Max Workpiece Height
400 mm

Axis Travel (X/Y/Z)
400 x 320 x 300 mm

Max Taper Angle
6 at 80 mm height

Max Workpiece Weight
350 kg

Min Wire Diameter
0.15 mm

Max Table Load
350 kg

Software Compatibility
Standard G-Code, DXF

Work Table Size
600 x 400 mm

Machine Installation Area
2000 x 1500 mm

Material Capability
Steel, Carbide, Copper, Tungsten

FZT-400 FZT Series EDM Wire Cut Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
1 Piece Per Week

Delivery Time
1-2 Week

FZT-400 FZT Series EDM Wire Cut About

Buy the FZT-400 FZT Series EDM Wire Cut for remarkable precision at the lowest price. This stellar CNC EDM machine features a breathtaking working speed of up to 100 mm2/min, supporting a max workpiece height of 400 mm and weight of 350 kg. Select this powerhouse for advanced accuracy of 0.015 mm, automatic threading, variable conveyance speed, and a 17-inch LCD touch screen. Admired for high performance, stability, and simple operation, it accommodates steel, carbide, copper, and tungsten. Secure your competitive edge-choose FZT-400, a remarked investment for mold manufacturing, tool parts machining, and precision cutting needs.

FZT-400 Wire Cut: Precision Applications Across Industries

The FZT-400 FZT Series EDM Wire Cut excels in high-precision environments such as mold fabrication, tool component manufacturing, and intricate machining of steel, tungsten, and copper. Common application sites include mold shops, tool and die manufacturers, and industrial workshops. With its rigid frame and advanced CNC control, the FZT-400 delivers exceptional finishes on surfaces where superior accuracy matters, making it the preferred choice for complex geometries and tight tolerances in demanding production settings.

Supply, Payment, and Export Markets for FZT-400 Series EDM

Our supply capacity ensures swift freight dispatches for both large and small outlays. The FZT-400 is ready for worldwide shipment, addressing the needs of diverse industries. Standard payment terms offer flexibility, streamlining your acquisition process. We serve export markets across Asia, Europe, and the Middle East, ensuring steady availability and reliable after-sales support. Partner with us as your trusted exporter, trader, and supplier for consistent, high-quality EDM solutions.

FAQ's of FZT-400 FZT Series EDM Wire Cut:

Q: How does the FZT-400 EDM Wire Cut achieve such high precision in workpiece machining?

A: The FZT-400 utilizes advanced CNC technology and a servo motor drive to ensure cutting accuracy of 0.015 mm. Its automatic wire threading system and stable, rigid structure further enhance precision, especially when working with challenging materials like carbide and tungsten.

Q: What materials can be processed using the FZT-400 Wire Cut machine?

A: The FZT-400 is engineered to machine hard materials such as steel, carbide, copper, and tungsten, making it ideal for tool parts production and mold manufacturing applications.

Q: Where is the FZT-400 EDM Wire Cut most commonly used?

A: This machine is widely used in industrial sectors including mold shops, tool manufacturing plants, and precision engineering workshops where high accuracy and efficiency in cutting are critical.

Q: When can I expect delivery after placing a supply order for the FZT-400?

A: Delivery timelines depend on your location and order volume, but our efficient supply logistics and robust freight partnerships ensure prompt dispatch, minimizing wait times for both domestic and international shipments.

Q: What is the process for integrating the FZT-400 into an existing production line?

A: The FZT-400 features standard G-Code and DXF compatibility for seamless integration with established CNC workflows. Connecting via USB or RS232 and setting up the machine is straightforward, aided by its easy-to-use software and touch-screen interface.

Q: How does the FZT-400 benefit my manufacturing operations?

A: With 24/7 production capability, low noise, and a water-cooled, automatic lubrication system, the FZT-400 delivers consistent high-quality cuts, reduces downtime, and increases operational efficiency on a variety of hard materials.
