BML6436 - Universal Swivel Head Milling Machine

Send Inquiry

Request To Call Back

BML6436 - Universal Swivel Head Milling Machine

Name: BML6436 - Universal Swivel Head Milling Machine
Brand: BERLIN MACHINERIES PRIVATE LIMITED
Price: 1468943 INR
Availability: InStock

Price 1468943 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

BML6436 - Universal Swivel Head Milling Machine Specification

Production Capacity
Variable

Features
Swivel Head, Digital Readout, Heavy Duty Structure, High Precision, Wear Resistant Gears

Drive
V-Belt Drive

Power Rating
3.7 kW

Machine Type
Universal Swivel Head

Cooling System
Integrated Coolant System

Lubricating System
Automatic Lubrication

Model No
USM-550

Motor Power
5 HP

Frequency
50 Hz

Connectivity Options
Digital Readout (optional USB Data Output)

Accuracy
0.02 mm

Frame Type
Rigid Cast Iron Frame

Operating Temperature
5C to 40C

Noise Level
<76 dB

Voltage
415 V

Product Type
Universal Swivel Head Milling Machine

Technology
Conventional

Power Source
Electric

Power
5 HP

Surface Treatment
Paint Coated

Dimension (L*W*H)
2200 x 1700 x 2050 mm

Weight (kg)
2100 kg

Color
Blue & White

Usage & Applications
Metal Cutting, Drilling, Boring, Slotting, Milling

Coolant Pump Power
40 W

Swivel Range of Milling Head
45

Distance from Spindle Center to Table
160-560 mm

Number of Feeds
12

Table Size
1320 x 320 mm

Distance from Spindle Nose to Table
0-400 mm

Cross Travel (Y)
350 mm

Spindle Taper
ISO 40

Max. Table Load
450 kg

Rapid Feed
Yes

Longitudinal Travel (X)
1050 mm

Working Speed
60-1800 RPM

Main Spindle Speed Steps
12 Steps

Vertical Travel (Z)
400 mm

BML6436 - Universal Swivel Head Milling Machine Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
1 Unit Per Month

Delivery Time
1-2 Week

BML6436 - Universal Swivel Head Milling Machine About

Grab a grand opportunity to enhance your workshop with the Universal Swivel Head Milling Machine-an absolute virtuoso in versatility and precision! Engineered with a stellar 5 HP motor and ISO 40 spindle, this machine offers 12 speed steps and a digital readout for accurate metal cutting, drilling, boring, slotting, and milling. The robust cast iron frame and automatic lubrication system ensure lasting performance, while wear-resistant gears boost reliability. Don't wait-grab yours now and experience first-class machining for every project!

Versatile Precision for Every Application

The Universal Swivel Head Milling Machine excels in both specific and general machining operations. Its wide working range, digital accuracy of 0.02 mm, and 45 swivel head make it an ideal choice for precise metal cutting, drilling, boring, and slotting on various surfaces. Suitable for complex industrial tasks as well as general workshop needs, this heavy-duty machine ensures efficient production with minimal downtime, regardless of your application surface or scale.

Domestic Market Support and Certifications

Stock ready for immediate delivery across the domestic market, this machine is certified for stringent industrial standards. Featuring a comprehensive sample policy for interested buyers, the Universal Swivel Head Milling Machine is dispatched promptly to meet urgent production needs. Its strong presence in India as an exporter, manufacturer, supplier, trader, and wholesaler ensures reliable after-sales service and support, making it a smart investment for any business aiming for quality, compliance, and efficiency.

FAQ's of Universal Swivel Head Milling Machine:

Q: How does the swivel head feature enhance machining capabilities?

A: The 45 swivel head allows for greater flexibility when working on complex angles and shapes, making it easier to tackle specialized tasks beyond basic milling operations.

Q: What advantages does the integrated cooling and lubrication system offer?

A: The integrated coolant and automatic lubrication systems help reduce heat and friction during heavy-duty operations, prolonging machine life and ensuring smooth, precise finishes.

Q: When should I use the rapid feed function on the milling machine?

A: Use the rapid feed feature during non-cutting movements to save time when positioning the table, improving overall workflow efficiency in both batch and single-piece production.

Q: Where can this machine be used in terms of industrial applications?

A: This milling machine is suited for a broad range of industries including manufacturing, automotive, aerospace, and general metalworking workshops requiring precise and versatile metal machining.

Q: What is the benefit of the digital readout and optional USB data output?

A: The digital readout enhances machining accuracy, while the optional USB output provides connectivity for data logging and job monitoring, supporting quality control and production diagnostics.
